Electro-hydraulic operated directional valve 4WEH
Highlights and Innovations
1.Precise low-current control of high-flow hydraulic oil.
2.Robust valve body withstands over 35 MPa pressure.
3.Wet-pin solenoid technology reduces wear and nois.
4.Special seals and coatings for harsh conditions.
5.Precise directional control of actuators.
- Feature
- Model code
- Related Products
Feature:
1. 4WEH series electro-hydraulic operated directional valves is controlled by solenoid valve a s pilot, using plate connection and its size meets DIN2430 and SO4401.It has many different properties and additional devices are available.
2. Solenoid valve, used as pilot control, has wet-type DC or AC series; the main valve adopts spring centralizing and spring-return, hydraulic centralizing and resetting with or without reversing time regulator; with or without the main valve stroke regulator; pre-pressure valve can be mounted in the main valve; cartridge damper can be mounted: pressure reducing valve can be mounted when operating pressure over 25Pa
| Product | 4WEH |
| Application |
1.Injection Molding Machine 2.Heavy-duty Press 3.Construction Machinery 4.Metallurgical Equipment 5.Marine Deck Machinery |
| Displacement/Size | 10,16,22,25,32 |
| Control types | Electro-hydraulic control |
| Max pressure | 350 Bar |
| Max Speed | / |
| Max Flow | 1100 L/min |
| Material | Cast Iron |
| Guarantee Period | / |
| Customization or not | / |
