Modular valve ZDB
Highlights and Innovations
1. Direct-operated design with poppet type construction
2. Excellent pressure stability with minimal hysteresis
3. Fast response characteristics for quick pressure adjustment
4. Low noise operation even at high pressure settings
5. Compact sandwich design for easy installation
- Feature
- Model code
- Related Products
Feature:
1. ZDB type modular pilot relief valve is assembled by valve body and one or two insert type pilot relief valve.
2. The valve has six kinds of control type and four pressure grades. It can adjust and limit system pressure.
| Product | ZDB |
| Application |
1. Industrial hydraulic power units 2. clamping and feeding circuits 3. Plastic injection molding machines 4. Mobile hydraulics on construction machinery 5. Test rigs |
| Displacement/Size | ZDB6ZDB10 |
| Control types | knob; adjusting-bolt with protection cover; lockable knob with scale; knob with scale |
| Max pressure | 31.5 MPa |
| Max Speed | / |
| Max Flow | 100(L/min) |
| Material | Housing made of high-strength steelInternal components using hardened steel and brassSealing elements from standard nitrile rubber compounds |
| Guarantee Period | / |
| Customization or not | / |
