Internal Gear pump HG
Highlights and Innovations
Tilted Saddle Design for Cylinders, High-Pressure Compact Gear Pumps, Pneumatic to Hydraulic Pressure Boosting, Mobile Power Conversion, Corrosion and Wear Resistance.
- Feature
- Model code
- Related Products
Features:
1.The axial and radial pressure compensation design is adopted to maintain high volumetric efficiency even at low speed and low viscosity. The ultra-low noise is made by using high-strength cast iron and unique internal noise reduction design to reduce the noise
2.With extremely low flow and pressure pulsation, stable flow and pressure output can still be maintained at low speed. With high pressure design, the maximum operating pressure can reach 35 MPa.
3.The speed range is wide, and the maximum speed can reach 3000 r/min· It can be combined to form a duplex pump
4.It is insensitive to oil pollution and has a long service life
5.It can be widely applied to hydraulic systems in industries such as plastic machines, shoe machines, die-casting machines and forklift trucks, especially to energy-saving systems driven by servo frequency conversion
| Product | HG |
| Application | Engineering and Construction Machinery,Injection Molding and Metal Forming Machines,Industrial Presses and Clamping Equipment,Machine Tools,Mobile Machinery and Vehicles |
| Displacement/Size | 8,10,13,16,20,25,32,40,50,63,80,100,125,145,160 |
| Control types | / |
| Max pressure | 35 MPa |
| Max Speed | 3000rpm |
| Max Flow | / |
| Material | Cast Iron |
| Guarantee Period | / |
| Customization or not | / |
| SPECIFICATION | |||||||
| MODEL | SIZE | DESP.mL/r | PRESSURE MPa | ROTAT ING SPEED r/min | WEIGHT kg | ||
| RATED MAX | MAX MIN | ||||||
| HG0 | 8 | 8.0 | 25 | 30 | 3000 | 600 | 4.4 |
| 10 | 10.0 | 31.5 | 35 | 3000 | 600 | 4.6 | |
| 13 | 13.3 | 31.5 | 35 | 3000 | 600 | 4.9 | |
| 16 | 16.0 | 31.5 | 35 | 3000 | 600 | 5.2 | |
| 20 | 20.0 | 31.5 | 35 | 3000 | 600 | 5.6 | |
| HG1 | 25 | 25.3 | 31.5 | 35 | 3000 | 200 | 14.5 |
| 32 | 32.7 | 31.5 | 35 | 3000 | 200 | 15 | |
| 40 | 40.1 | 31.5 | 35 | 3000 | 200 | 16 | |
| 50 | 50.7 | 31.5 | 35 | 3000 | 200 | 17 | |
| 63 | 63.7 | 31.5 | 35 | 3000 | 200 | 18.5 | |
| HG2 | 80 | 81.4 | 31.5 | 35 | 3000 | 200 | 43.5 |
| 100 | 100.2 | 31.5 | 35 | 3000 | 200 | 45.5 | |
| 125 | 125.3 | 31.5 | 35 | 3000 | 200 | 48 | |
| 160 | 162.8 | 21 | 26 | 3000 | 200 | 52 | |
